Clock Speeds Base Clock: 915 MHz Boost Clock: 2505 MHz Memory Clock: 2500 MHz 20 Gbps effective Memory Memory Size: 48 GB Memory Type: GDDR6 Memory Bus 384 bit Bandwidth 960.0 GB/s Render Config Shading Units: 18176 TMUs: 568 ROPs: 192 SM Count: 142 Tensor Cores: 568 RT Cores: 142 L1 Cache 128 KB (per SM) L2 Cache 96 MB Theoretical Performance Pixel Rate: 481.0 GPixel/s Texture Rate: 1,423 GTexel/s FP16 (half) 91.06 TFLOPS (1:1) FP32 (float) 91.06 TFLOPS FP64 (double) 1,423 GFLOPS (1:64) Board Design Slot Width: Dual-slot Length: 267 mm 10.5 inches Width: 112 mm 4.4 inches TDP: 300 W Suggested PSU: 700 W Outputs: 4x DisplayPort 1.4a Power Connectors: 1x 16-pin Graphics Features: DirectX 12 Ultimate (12_2) OpenGL 4.6 OpenCL Vulcan 1.3 CUDA 8.9 Shader Model 6.7 Card Notes 3 NVENC Engines AD102 GPU Notes Ray Tracing Cores: 3rd Gen Tensor Cores: 4th Gen NVENC: 8th Gen NVDEC: 5th Gen PureVideo HD: VP12 VDPAU: Feature Set L
